Description
BP86 liquid level transmitter can be used for the measurement of static pressure liquid level in the pharmaceutical, food, light industry, metallurgy, shipbuilding, sewage treatment and other industries.
Parameters:
|
Model |
BP86Z0 |
|
Measured medium |
Liquid compatible with 304/316 stainless steel, Viton and PVC, PU |
|
Range |
0 ～ 5kPa to 0 ～ 2MPa (or 0 ～ 0.5mH2O to 0 ～ 200mH2O |
|
Overload |
2 times the upper limit of the maximum measurement range |
|
Accuracy level |
99.5% |
|
Operating temperature range |
-10 ～ + 70 ℃ (for PVC cable); -25 ～ + 85 ℃ (for polyurethane cable) |
|
Compensation temperature range |
0 ～ 70 ℃ |
|
Output |
0-5V output 4 ～ 20mADC RS232 RS485 |
|
Power supply |
12 ～ 36VDC |
|
Electrical interface |
Direct cable exit |
|
Material |
Sensor probe material: SS304 or SS316 Cable outer sheath material: PVC or Polyurethane |
|
protection class |
Ip68 |
